3.81mm Pitch Straight Header with Mounting 2~20 Position UL ; CE Approved

Description

3.81mm Pitch Straight Header with Mounting

Download: Spec Sheet

Specifications:

Pitch3.81 mm
Poles2~20 Poles
Length AA=3.81xP+10.40mm
Housing MaterialPA 66
Pin DimensionsBrass, Tin Plated
ContactPhosphor Bronze, Tin Plated
Wire Size16 ~ 24
Wire Strip Length5-6mm
Tightening Torque, Max.3 Lb-in
Operating Temperature-40°C to +105°C




























SKU# P/NPOLEMOQ
16411641-MC421-022
200
16421642-MC421-033200
16431643-MC421-044200
16441644-MC421-055200
 16451645-MC421-066200
16461646-MC421-077200
16471647-MC421-088200
16481648-MC421-099200
16491649-MC421-1010200
16501650-MC421-1111100
16511651-MC421-1212100
16521652-MC421-1313100
16531653-MC421-1414100
 16541654-MC421-1515100
 1655 1655-MC421-1616100
16561656-MC421-1717100
16571657-MC421-1818100
 1658 1658-MC421-1919100
 1659 1659-MC421-2020100
